In Stock Graz Staircase
Graz Staircase
✅ Ultra-compact modern staircase – just 580mm wide
🚚 FREE UK Mainland Delivery — securely packaged and tracked
Adjustable rise system for flexible installation between 240cm–292cm
The Graz Staircase is a space-efficient domestic staircase designed for compact interiors where width and projection must be carefully managed without compromising strength or safety.
Technical
Floor-to-Floor Heights: 240cm – 292cm
Staircase Width: 580mm
Min Floor Opening Length: 1700mm
Min Floor Opening Width: 600mm
Tread Depth: 210mm
Structure Material: Powder Coated Steel
Tread Material: Multiplex wood with beech veneer
Max Load: 200kg
Use Type: Domestic
Certified to: EN 1991 & EN 1993
Guarantee: Lifetime Guarantee
Key Benefits
Ultra-Compact 580mm Width
Ideal for mezzanine floors, loft spaces and compact domestic layouts.Adjustable Rise System
Tread rise can be set between 18.5cm and 22.5cm to suit your exact floor height.Straight or Quarter-Turn Installation
Flexible configuration allows installation to suit room layout.Minimal Horizontal Projection
Approx. 170cm (straight) or 164–169cm (quarter-turn), keeping floor space usage efficient.Durable Beech Multiplex Treads
Varnished finish for durability and refined appearance.Powder-Coated Steel Structure
Available in Grey (RAL 9007) or Black (RAL 9005).Handrail Included
Supplied with one-side handrail and banisters for secure grip.Tested for Heavy Load Capacity
200kg point load and 560kg total load tested.Complete Kit Supplied
Delivered in one box with all components for installation.
📏 Sizes & Dimensions
| Specification | Measurement |
|---|---|
| Floor-to-Floor Height | 240cm – 292cm |
| Stair Width | 580mm |
| Total Going Length | 1.8m |
| Min Floor Opening Length | 1700mm |
| Min Floor Opening Width | 600mm |
| No. of Treads | 12 |
| No. of Risers | 13 |
| Tread Depth | 210mm |
| Tread Rise | 18.5cm – 22.5cm |
| Tread Thickness | 35mm |
| Max Load | 200kg |
Always measure your finished floor-to-floor height and floor opening before ordering.
How Does It Compare?
| Feature | Graz Staircase | Basic Compact Staircase |
|---|---|---|
| Width | ✔ 580mm ultra-compact | ✘ Often wider |
| Adjustable Rise | ✔ 18.5–22.5cm | ✘ Fixed rise |
| Installation Options | ✔ Straight or quarter-turn | ✘ Limited layout |
| Structural Certification | ✔ EN 1991 & EN 1993 | ✘ Often uncertified |
| Load Rating | ✔ 200kg | ✘ Lower |
| Included Handrail | ✔ Yes | ✘ Often extra |
The Graz offers a certified, adjustable and compact solution rather than a basic fixed stair kit.
Full Product Overview
The Graz Staircase is designed for modern domestic interiors requiring efficient use of space. With a slim 580mm width and adjustable rise system, it accommodates floor-to-floor heights between 240cm and 292cm while maintaining comfortable tread depth.
Its powder-coated steel frame provides structural stability, while varnished beech multiplex treads deliver durability and a refined finish. The staircase can be installed straight or configured as a quarter-turn, allowing flexibility to suit room layout constraints.
Tested to European structural standards and rated for a 200kg load, the Graz Staircase delivers reliable domestic performance in a compact footprint.
Safety & Build Details
Powder-coated steel load-bearing structure
35mm thick beech multiplex treads
Adjustable rise system for tailored installation
Handrail and banisters included
Tested to 560kg total load and 200kg point load
Complies with EN 1991 and EN 1993
Final Verdict
The Graz Staircase is a compact, structurally certified and highly adjustable domestic staircase ideal for mezzanine floors and loft spaces. With its 580mm slim width, flexible installation options and Lifetime Guarantee, it provides both safety and architectural style in one complete kit.
